Description
Pallet Spec or View full product spec PDF
The pallet has a reticular structure with excellent mechanical characteristics and a perimetric groove for housing the sleeve.
| Product code / Ref: | BCLP900 |
| Size: | (L) 1200 mm (W) 900 mm (H) 133 mm |
| Weight: | ?kg |
| Material: | PP |
| Colour/s: | Black |
| Dynamic load: | ?kg |
| Static load: | ?kg |
| Racking load: | – |
| Perimetrical groove: | Yes |
| Packing per stack: | ? |
| Other info: | Runners (optional) |
Sleeve spec
Made with a rimmed contour to prevent injuries and on request can be fitted to the pallet and the lid with 8 hooks.
| Product code / Ref: | BCLS900 |
| Size: | (L) 1200 mm (W) 900 mm |
| Internal dimensions: | (L) 1163 mm (W) 863 mm |
| Belt height: | Minimum 390 mm / maximum 1198 mm |
| Thickness: | From minimum 5mm to maximum 10 mm |
| Thickness: | Minimum 8.5 mm / maximum 10 mm |
| Density: | Minimum 1.5kg/m2 to maximum 3kg/m2 |
| Material: | PP |
| Colour: | On demand according to quantities (minimum 1000kg) |
| Other info: | Foldable door on one or two sides (optional) Option to fix belt to pallet and lid with 8 hooks Rimmed contour Foldable |
Lid spec
The upper part of the lid is made with a special structure to allow the stacking of the boxes.
| Product code / Ref: | BCLL950 |
| Size: | (L) 1200 mm (W) 900 mm |
| Weight: | ? kg |
| Material: | PP |
| Colour/s: | Anthracite grey |
| Other info: | Upper part of lid made with special structure to allow stacking of boxes Pull rings (optional) |
Why a 900 mm width exists
900 × 1200 mm sits between the Euro 800 and the UK standard 1000. It is not a compromise size — it exists because some vehicle beds, rack configurations and production cells take three 900 mm pallets across where they would only take two at 1000 mm, or waste space at 800.
If you have never had a reason to measure, you probably want 800 × 1200 or 1000 × 1200. If you have measured and neither fits cleanly, this is why the 900 exists.
The base
Reticular structure with good mechanical characteristics, and a perimetric groove that houses the sleeve so the assembled box stays square under load.
The return leg
Sleeve, base and lid separate, and the sleeve collapses onto the base when empty. On a closed circuit that decides how many empties come back per vehicle, which is usually where returnable packaging pays for itself rather than in the outbound leg.
Related sizes
See the full Lite Box range, or send us your vehicle bed and rack dimensions and we will work out which footprint loses you the least space.
