Description
Pallet Spec or View full product spec PDF
The pallet has a reticular structure with excellent mechanical characteristics and a perimetric groove for housing the sleeve.
| Product code / Ref: | BCLP1100 |
| Size: | (L) 1200 mm (W) 1100 mm (H) 133 mm |
| Weight: | 15 kg |
| Material: | PP |
| Colour/s: | Black |
| Dynamic load: | 1500 kg |
| Static load: | 3000 kg |
| Racking load: | – |
| Perimetrical groove: | Yes |
| Packing per stack: | 34 |
| Other info: | Runners (optional) |
Sleeve spec
Made with a rimmed contour to prevent injuries and on request can be fitted to the pallet and the lid with 8 hooks.
| Product code / Ref: | BCLS0800 |
| Size: | (L) 1200 mm (W) 1100 mm |
| Internal dimensions: | (L) 1163 mm (W) 1063 mm |
| Belt height: | Minimum 390 mm / maximum 1198 mm |
| Thickness: | From minimum 5mm to maximum 10 mm |
| Thickness: | Minimum 8.5 mm / maximum 10 mm |
| Density: | Minimum 1.5kg/m2 to maximum 3kg/m2 |
| Material: | PP |
| Colour: | On demand according to quantities (minimum 1000kg) |
| Other info: | Foldable door on one or two sides (optional) Option to fix belt to pallet and lid with 8 hooks Rimmed contour Foldable |
Lid spec
The upper part of the lid is made with a special structure to allow the stacking of the boxes.
| Product code / Ref: | BCLL0850 |
| Size: | (L) 1200 mm (W) 1100 mm |
| Weight: | 9 kg |
| Material: | PP |
| Colour/s: | Anthracite grey |
| Other info: | Upper part of lid made with special structure to allow stacking of boxes Pull rings (optional) |
1100 × 1200 and the export question
1100 × 1100 is the standard pallet across much of Asia and Australasia, and 1100 × 1200 sits close to it while keeping the 1200 mm depth used in UK and European handling. That makes this footprint worth looking at when goods move between UK distribution and containers loaded to Asian standards.
Inside a UK-only operation the 1000 × 1200 will normally fit the racking better.
Base construction
Reticular structure with good mechanical characteristics and a perimetric groove housing the sleeve, so the box holds its shape loaded.
Container loading
At larger footprints, how the pallet fits the container matters more than how it fits the rack. A footprint that leaves 100 mm spare down the length of a 40 ft container costs you nothing; one that leaves 400 mm costs you a pallet position on every row. That is worth working out before choosing a size, not after.
Empty return
The sleeve collapses onto the base, so empties stack down rather than travelling at full height — the point of a sleeved system rather than a rigid box.
See the full Lite Box range or ask us to work through your container loading.
